Ductile Iron Anti-static Ceiling Grate

Anti-static galvanized ductile iron grating in 1.22x3.66 m panels for suspended decorative ceiling grids. The open mesh hides ductwork and cables below the ceiling.
Custom cell sizes are available. FOB price US $1.9-10 per piece, minimum order 10 pieces.
Send Inquiry
Product Introduction

Ductile Iron Anti-static Ceiling Grate

Open grid below a suspended decorative ceiling

This grate forms the open grid of suspended decorative ceilings, where architects want a permeable metal face below the room rather than a closed solid panel. The open mesh hides ductwork, cable trays and sprinkler runs above the ceiling while letting air move through the grid between room and plenum, and the bars read as a regular geometric pattern from the finished floor below. Ceiling grids span between suspension hangers fixed to the structural slab, and the panel edge bars clip or rest on those hanger rails so the grid stays level across the room width. The listed panel measures 1.22x3.66 m, and the ductile iron body carries the panel weight above an interior space without vehicular load. In offices, lobbies and corridor fit-outs, the open grid also leaves access routes for technicians who lift a section to reach services above the ceiling line. Panel weight above the room stays light enough for two fitters to position on the hanger rails without lifting equipment.

The grid hides services in the plenum. Air passes through the open mesh between room and above.

Anti-static body around cabling and ductwork

The anti-static designation on this panel matters where the grid sits above electronic cabling, signal circuits and equipment rooms, because a static-conductive metal body helps dissipate surface charge rather than letting it build on an insulating panel. Ductile iron behind the finish forms a conductive section that the fit-out team can bond according to the project's own grounding practice, and the open construction keeps the grid from trapping dust against cable runs. Above the ceiling, conditions are dry compared with a wet process floor, so the galvanized surface mainly guards against ambient humidity and the occasional condensation drip from ductwork. The listing leaves certification record, intended service, pressure class, joint form and model reference open, so electrical bonding details are settled with the fit-out engineer rather than assumed from the panel alone. Where the grid borders a lighting strip or a bulkhead, panel ends are cut square to that ceiling line.

The conductive body helps dissipate static near cabling. Bonding details follow the fit-out engineer's practice.

Anti-static ductile iron grate panel forming a suspended ceiling grid
Open metal grid panels staged below an interior decorative ceiling.

Cell size chosen for the ceiling module

Ceiling grids follow a module set by the room plan, and the cell size of the grate mesh is chosen to read as a regular pattern against that module, neither too coarse to look heavy in a low ceiling nor too fine to conceal the services above. The listed panel band 1.22x3.66 m provides the standard section, and custom cell sizes are accepted where the ceiling module calls for a tighter or wider opening than the standard layout. Bar spacing across the panel keeps the grid even across the full room, and panel seams align so the pattern continues without a broken line at the joint. Suspension hangers support the panel at regular intervals marked on the ceiling layout, and the finished grid sits level so light from below reflects off the bar tops evenly. Where a service access hatch drops from the grid, the neighboring panels are trimmed around that opening.

Cell size matches the ceiling module. Seams keep the bar pattern continuous across the room.

CellValue
Listed dimensions1.22x3.66 m panel
Body materialDuctile Iron
Product categoryGrating
Listed form-
Certification record-
Intended service-
Load class band-
Model reference-
Edge and joint form-

Concealing services above the finished room

Above a suspended ceiling, supply and return ductwork, electrical cable trays, sprinkler pipes and sometimes water lines run together in the plenum space, and the open grate grid screens that clutter from the room side without closing off air movement or access. Technicians working above the grid can reach cable pulls and duct dampers by lifting a panel section, which keeps the ceiling face intact between visits rather than requiring a permanent removable hatch at every service point. The metal body does not absorb moisture, and it does not shed fibrous dust the way some composite ceiling tiles do, which suits rooms where clean air matters. The grid line aligns with wall finishes and bulkheads, and edge panels are cut to follow the room perimeter rather than leaving a ragged gap at the wall. Routine building rounds check that hanger fixings remain tight and that no panel has dropped out of the rail after fit-out settlement.

The grid screens plenum clutter while leaving access open. Panels lift for cable and damper work above.

Ceiling grid order notes

The listed bracket runs US $1.9-10 per piece, ten pieces being the order floor; the delivery window follows the quotation, and panels carry the YH mark made in China. Type field, model reference, certification record, intended service, joint form and pressure class carry no assigned value on the listing, so those entries are confirmed against the interior fit-out drawing at order stage. Custom cell sizes and cut edges are accepted where the ceiling module falls outside the standard family. Before packing, the shop checks panel dimensions, bar alignment and surface finish across each section, and edge protectors keep the galvanized rim intact through handling to site.

Ten pieces starts the batch. Cell layout follows the room ceiling module drawing.
